So long Sulphur emissions:

navigating the new IMO regulations

In January 2020 the shipping industry, and those supplying its fuel, face one of the biggest challenges in decades. Andrew Tunnicliffe finds out how the sector is preparing for the next adaptation of the MARPOL Convention

Image courtesy of

Since the mid 2000s,

the shipping industry has been required to meet standards on air pollution. However, the sector and its supply chain are facing an uncertain future as the International Maritime Organization (IMO) prepares to strengthen regulations at the end of the year, and the “stakes are high for operators,” says Duygu Doğan, senior associate at Kılınç Law & Consulting.

As of 2005, ship operators have had to control the level of sulphur oxides (SOx) their fleets produce under Annex VI of the International Convention for the Prevention of Pollution from Ships (MARPOL Convention). SOx, a byproduct of burning the unrefined heavy bunker fuel, is known to be harmful to people and the planet but the damage it causes can be catastrophic, as Doğan explains: “Sulphur oxides have been linked with respiratory problems in humans and acid rain.”

According to HSBC Oil and Gas Research, a single container ship burning 80 tonnes of fuel per day emits the same amount of sulphur oxides as 46 million diesel cars. A Finnish study published in 2016 warned their adverse health effects could result in more than 570,000 premature deaths worldwide between 2020-25. With statistics like that, it is no surprise steps are being taken to cut levels of emissions even further.

In 2008 the IMO strengthened its global emissions limits and introduced Sulphur Emissions Control Areas (ECAS), where even more robust requirements applied. The global limit was set at 3.5% m/m (mass by mass) and just 0.1% in ECAS, which covers coastal areas of the Baltic Sea and North Sea, Canada and the US, including Puerto Rico and the US Virgin Islands.

On 1 January 2020 those limits will be cut again: “The IMO’s new regulations require the sulphur content of ships’ fuel to be cut dramatically, from 3.5% to 0.5%,” explains Doğan. “Alternatively, the regulations allow ship operators to fit scrubbers, which spray alkaline water over exhaust emissions, capturing sulphur oxides.”

The challenge these regulations pose the industry – comprising more than 94,000 vessels, according to the United Nations – are significant, with concerns that many are not ready: “Ship operators are racing to achieve compliance by the end of the year, but the shift to low sulphur emissions is proving costly,” says Doğan. “Low sulphur fuels cost more, and the installation of scrubbers typically costs between $5m and $10m per ship.”

Stuart Rivers, CEO of Sailors’ Society.
Image courtesy of Sailors’ Society

Meeting IMO regulations is costly

According to a 2018 survey by maritime consultants Drewry, 66% of ship operators are opting for low sulphur fuels; however, that comes at a price too. “Low sulphur fuel costs around €250 more per tonne than standard heavy fuel oil,” Doğan says, “and some fear that when the new regulations kick in demand will skyrocket, with analysts predicting the price difference could rise to nearer $400.”

Low sulphur fuel costs around €250 more per tonne than standard heavy fuel oil

Another option is liquified natural gas (LNG), with one in four ship operators (24%) considering making LNG-ready ship purchases according to Drewry.

“LNG certainly does seem to be becoming increasingly popular when new ships are being ordered,” remarks Doğan. Some are converting their existing fleet, such as Hapag-Lloyd which has announced plans to convert 17 vessels, costing in the region of $25m per vessel. Maersk has said it is also looking at converting existing ships.

Image courtesy of

Image courtesy of

Challenges for refiners

For now, however, refiners face a huge challenge according to Stephen George, chief economist with KBC: “The IMO 2020 regulation has been described as the most disruptive change to impact the oil industry in the last 30 years.”

Refiners, bunker fuel blenders, and marketers will have to produce a range of new fuels to meet emerging demand, he says: “Since we’ve never done this before, it is hard to forecast everything that could happen, but certainly the supply chain will have to re-invent its formulations, transmission and storage systems, possibly offering more grades of fuel to meet a wider range of shipping demands.”

He says the sector has four options: residue destruction to exit the fuel oil market completely; residue desulphurisation to produce lower sulphur compliant bunker; change the feed slate for sweeter or lighter crudes; or do nothing and hope to ride out the turbulent period.

“What’s for certain is that bunker fuel won’t be made like it is now,” he adds.

IMO 2020 has been described as the most disruptive change to impact the oil industry in the last 30 years

In a comment piece by UKPIA – which represents some of the UK’s downstream oil industry – Hugh Tucker warned refining margins could weaken if the sector fails to invest as a result of the regulations, challenging the commercial viability of some operations. Such an environment will impact ship operators.

Some have already spent, and big, on preparing for 2020 and they will want to recoup some of that.

“Refiners have invested in new technology like residue hydrocracking and delayed coking,” George says. “These are expensive process units to reduce the amount of high sulphur residue they are producing. They will be looking for the wider price spread to generate the ‘crack spreads’ that will help to repay the cost of these big-ticket investments.”

Image courtesy of balipadma / Shutterstock.com

Non-compliance is not an option

With uncertainty over fuel prices - but the expectation they will only rise - the shipping industry faces some significant challenges. According to Wood MacKenzie, it could cost the sector up to as $60bn a year, something Doğan claims will “inevitably result in increased shipping costs and, in turn, inflate the cost of shipped goods and raw materials."

George agrees: “The real risk to shipowners is that they will be obliged to buy expensive low sulphur bunker. In turn they will have to raise their rates.”

It’s fair to say the global shipping industry is in a state of flux and not likely to change any time soon. Although the IMO regulations were announced more than three years ago, many shipping companies remain undecided on how best to meet them. But meet them they must.

Refiners, ship owners, bunkering companies and traders will all play a key role in delivering this clean energy transition

“The owners of a non-compliant vessel could face fines, or might even have their vessel declared un-seaworthy which would mean it could not be put to sea until it becomes compliant. There are also risks that insurance policies could be invalidated,” Doğan warns.

Refineries will also be under pressure, says George: “The burden of proof of compliance will fall to the ship operators, but refiners and especially blenders will need to certify that the fuels they are bringing to market meet the ISO 8217 specifications and the sulphur and compatibility requirements of their clients.”

Doğan believes the new regulations will result in a significant reduction in global sulphur emissions, benefiting human health and the planet. “This won’t happen overnight,” however, says George. “Refiners, ship owners, bunkering companies and traders will all play a key role in delivering this clean energy transition.”

Futureproofing the shipping industry

For ship operators already satisfied they are compliant, there is no time for complacency. “An interesting knock-on effect of these regulations is that their global scope provides a potent example of the power and reach of the IMO as an international regulator,” continues Doğan.

Ship operators need to anticipate future regulatory trends before they happen

“Many in the shipping industry believe that their eventual success may encourage the IMO to implement further environmental regulation. Ship operators need to anticipate future regulatory trends before they happen, and choose vessels that are easy to adapt when the regulatory environment changes,” she concludes.

Despite the challenges refiners face, there is a silver lining according to George: “IMO 2020 may provide a golden opportunity to futureproof a refinery, even if the investment isn’t completed until closer to mid-decade.”
